SCM Nova Model TF100 Spindle Moulder
£3,459.00
The SCM Nova TF100 is a compact, professional spindle moulder designed for accurate shaping, profiling and routing of timber components. Built for ease of use and reliable performance, it provides consistent results for a wide range of joinery applications.
Product Features
- Fixed spindle moulder for shaping, profiling and light tenoning
- Four spindle speeds up to approx. 10,000 rpm
- Heavy-duty cast iron table and column for stability
- Manual rise and fall with mechanical readouts for precise setup
- Fence with mechanical programming for accurate positioning
- Maximum tool diameter approx. 240 mm
- Spindle height around 125 mm for standard tooling
- Reverse spindle rotation for added flexibility
- Prepared for power feed attachment
- Designed for professional workshop use
Description
The SCM Nova TF100 is an entry-level professional spindle moulder designed for workshops that need dependable accuracy in a simple and easy-to-use format. As part of the SCM Nova range, it offers a practical balance of performance, flexibility and straightforward operation, making it well suited to smaller workshops or those carrying out a mix of general joinery tasks.
At its core is a fixed spindle system supported by a rigid cast iron column and table, providing stability and reducing vibration during operation. This allows the machine to deliver clean and consistent results when carrying out profiling, moulding, rebating and light tenoning work. The spindle is driven by a powerful motor and operates across four selectable speeds, allowing it to handle a range of tooling sizes and materials efficiently.
The machine is designed with simplicity in mind. All movements are adjusted using front-mounted hand wheels with mechanical readouts, allowing precise control over setup without the need for repeated test cuts. The spindle moulder fence features mechanical programming and digital-style indicators, enabling accurate positioning of the worktables down to fine tolerances and improving repeatability across jobs.
With the ability to accommodate tooling up to around 240 mm in diameter and optional accessories for extended applications, the Nova TF100 offers flexibility for a wide range of woodworking tasks. Its straightforward design, combined with solid construction and reliable accuracy, makes it a strong choice for workshops looking for a dependable spindle moulder without the added complexity of higher-end machines.
Specifications
Spindle height diam. 30-35 (40-50) mm125 (125)
Spindle speed (at 50 Hz) rpm3500/6000/8000/10000
Max. diameter of the profiling tool 240mm
Max. tool diameter retractable under the table at 90°mm240
Three-phase motor power starting from:kW/Hz5 (6) / 50 (60)
| Work Table Dimensions | 1080 x 655mm |
| Working Length Of CE Spindle 30-35 (40-50) Diameter | 125 (125)mm |
| Max. Tool Diameter Retractable Under Table | 240 x 80mm |
- Work Table dimensions mm 1080×655
- Length of the CE spindle – diameter 30-35 (40-50) mm 140 (180)
- Spindle speed r.p.m. 3500/6000/8000/10000
- Max. tool diameter retractable under the table mm 240×80
- Diameter of extractor outlet on fence and base mm 120
- Main motor power KW(Hp) 5 (6.6) 50 Hz
- Net weight basic machine Kg 310
