SCM Profiset 40 4 Sided Planer
£15,550.00
The SCM Profiset 40 is a versatile all-in-one spindle moulder, planer, and thicknesser for small to mid-sized workshops. It features an idle roller for smooth feed and programmable feed speeds for precise timber processing. Ergonomic controls and automatic spindle positioning ensure safe, efficient, and accurate operation.
Product Features
- Combined planer, thicknesser and spindle moulder
- Compact multi-function machine design
- Programmable feed speed control
- Electronic positioning of vertical and horizontal spindles
- Ergonomic control panel layout
- Improved feeding with outfeed idle roller
- Smooth and stable material feed system
- Suitable for profiling and straight planing
- Space-saving workshop solution
- High-precision machining performance
Description
Combining a spindle moulder, planer and thicknesser all in one safe and ergonomic machine – the high-quality and robustness of SCM’s engineering are present more than ever in the SCM Profiset 40 Planer. Without taking up a great deal of space, the Profiset 40 is an excellent choice for smaller to mid-sized workshops.
Cost-effective, safe and efficient, the Profiset 40 makes for the effortless, yet high-quality production of straight-planed, profiled timber and more. Feeding has been greatly improved with the addition of an idle roller placed on the outfeed table – a standard feature of industrial machines. The feed speed can be set with ease with one push of a button.
Ease-of-use and a great degree of control are within arms reach of the operator thanks to the ergonomically located control panels. This focus on ergonomics allows for a more efficient operating process and makes for smooth, stable movement of the workpiece.
The addition of electronic controls makes for the automatic positioning of the left vertical spindle and top horizontal spindle. Feed speed can also be programmed and adjusted with the controls which allows for more effective management of the feed speeds.
Specifications
- Automatic 4 head through feed planer
- Capacity 180 x 105mm
- Powered feeding group before surfacer
- Tersa cutter block
- 1.7m infeed table (2.3m option available)
- Min Working width 23mm
- Max working width 180mm
- Min working height 6mm
- Max working height 105mm
- Feed speed 6-12m/min
- Spindle speed 6000 rpm
- Spindle dia 35mm
- Infeed table length 1700mm
- Motor 1 & 2 10hp
- Feed motor 1hp
| Min./max. working width (finished section) | mm | 25 (15 opt.)/230 |
| Min./max. working height (finished section) | mm | 6/120 |
| Feed speed | m/min | – |
| Feed speed (variable with inverter) | m/min | 5/25 |
| Spindles speed | rpm | 6000 |
| Axial adjustment of spindles with respect to the worktable | mm | 40 |
