POA
For professional workshops and demanding craftsmen, the SCM Model SI300S-400 Nova 1.6m Sliding Table Panel Saw is a powerful and robust machine capable of handling heavy workloads.
The closed-loop structure of the saw unit makes for the absence of disruptive vibrations which hinder efficiency and productivity. The closed-loop structure ensures that the blades are perfectly aligned during tilted and difficult cuts.
With sliding bearings running on hardened steel guides, smooth movement during operation is guaranteed. The wide section of the carriage and its closed reticular geometry provides additional rigidity and minimum deflection. Thanks to the dedicated gearbox, fully protected from dust – ease of use is inherent with smooth and direct transmission. Blade adjustments correspond accurately with the ergonomic handwheel.
For more information
If you are looking to swap out your older machine for a brand new model, fill in this short form.
Finance available on this machine working alongside our partner Close Brothers Asset Finance.
IMPORTANT
Specifications | |
|---|---|
Make | |
Model | |
Pre Milling Unit | |
Minimum Panel Length | |
Edge Thickness | |
Minimum Panel Thickess | |
End Trim | |
Motor Power | |
Corner Rounded | |
Scraping |
Specifications | |
|---|---|
Bander Type | |
Feed Speed | |
Maximum Edge Thickness | |
Minimum Edge Thickness | |
Top/bottom Trim | |
Buffing | |
Dust Outlet Size | |
Voltage/Phase | |
Weight | |
Dimensions |
FEATURES
SCM 10 year sliding table Guarantee
Sliding table stroke 1.6m
Blade dia 400mm
Kit 140mm cut height including Overhead gantry guard
Motor power 7.5hp
Independent scorer 120mm 0.75 Kw
Rip fence capacity 1270mm
Heavy Duty overhead saw guard
| Max. saw blade diameter with mounted scorer | mm / inches | 315 / 12 |
| Saw Blade arbor size | mm / inches | 25 / 1 |
| Maximum saw blade projection from table to 90°/45° | mm / inches | 100/70 3.9/2.75 |
| Cutting width on rip fence (Rip capacity) | mm / | 1270 |
| Max. squaring stroke of sliding table saw | mm / inches | 1600 / 63 |
| Three-phase motor | Hp | 11 |
| Independent scoring motor | Hp | 1 |
