SCM Gabbiani S Range Beam Saw

Both a perfect match for an advanced woodworker and smaller to mid-sized workshops – the SCM Gabbiani S Range Beam Saw is a compact, single-blade beam saw designed to cut solid wood panels and panel stacks.

Each table section has an air blowing device that can be enabled/disabled via independent motors, ensuring that the sliding of panels is free of errors and the accidental falling of cut panels. Additionally, tool changing has been greatly simplified and can be executed swiftly thanks to the “saw-set”. The electronic settings allow for fast and precise tool adjustments – boosting both ease-of-use and productivity.

The Maestro Cut feature involves easy-to-use, powerful programming that allows the creation of all panels imaginable. The interface is intuitive, reliable and customizable and assists in tending to the more specific requirements of clients.

Categories ,
Request Quote

Part Exchange

If you are looking to swap out our older machine for a brand new model? Fill in this short form.

Both a perfect match for an advanced woodworker and smaller to mid-sized workshops – the SCM Gabbiani S Range Beam Saw is a compact, single-blade beam saw designed to cut solid wood panels and panel stacks.

Each table section has an air blowing device that can be enabled/disabled via independent motors, ensuring that the sliding of panels is free of errors and the accidental falling of cut panels. Additionally, tool changing has been greatly simplified and can be executed swiftly thanks to the “saw-set”. The electronic settings allow for fast and precise tool adjustments – boosting both ease-of-use and productivity.

The Maestro Cut feature involves easy-to-use, powerful programming that allows the creation of all panels imaginable. The interface is intuitive, reliable and customizable and assists in tending to the more specific requirements of clients.

Both a perfect match for an advanced woodworker and smaller to mid-sized workshops – the SCM Gabbiani S Range Beam Saw is a compact, single-blade beam saw designed to cut solid wood panels and panel stacks.

Each table section has an air blowing device that can be enabled/disabled via independent motors, ensuring that the sliding of panels is free of errors and the accidental falling of cut panels. Additionally, tool changing has been greatly simplified and can be executed swiftly thanks to the “saw-set”. The electronic settings allow for fast and precise tool adjustments – boosting both ease-of-use and productivity.

The Maestro Cut feature involves easy-to-use, powerful programming that allows the creation of all panels imaginable. The interface is intuitive, reliable and customizable and assists in tending to the more specific requirements of clients.

Specifications

Cutting length mm3200/3800/4500
Blade projection mm 95115
Saw carriage variable speed (option)m/min6 – 60 (0 – 135 / 0 – 150)
Pusher variable speed (option)m/min 0 – 60 (0 -70 / 0 – 120)
Main blade motor S6 – 40% (option)kW7 (9 – 11 – 15)9 (11 -15 – 18)
Scoring unit blade motor 50 HzkW1,8
Main blade / scorer speed 50 Hzr.p.m.3900/6300
Main blade / scorer blade diameter mm380/160400/160
Number of clampsstd56

Cutting length 3300/3800/4300 mm
Blade projection 95 or 115 mm
Saw carriage variable speed 6 – 60 m/min
Pusher variable speed (option) 0 – 60 m/min
Main blade motor S6 – 40% (option) 7 (9) kW
Scoring unit blade motor 50 Hz (option) 1,3 kW
Main blade / scorer speed 50 Hz 4600/6300 rpm
Number of clamps standard 5

Specifications

Cutting length mm3200/3800/4500
Blade projection mm 95115
Saw carriage variable speed (option)m/min6 – 60 (0 – 135 / 0 – 150)
Pusher variable speed (option)m/min 0 – 60 (0 -70 / 0 – 120)
Main blade motor S6 – 40% (option)kW7 (9 – 11 – 15)9 (11 -15 – 18)
Scoring unit blade motor 50 HzkW1,8
Main blade / scorer speed 50 Hzr.p.m.3900/6300
Main blade / scorer blade diameter mm380/160400/160
Number of clampsstd56

Cutting length 3300/3800/4300 mm
Blade projection 95 or 115 mm
Saw carriage variable speed 6 – 60 m/min
Pusher variable speed (option) 0 – 60 m/min
Main blade motor S6 – 40% (option) 7 (9) kW
Scoring unit blade motor 50 Hz (option) 1,3 kW
Main blade / scorer speed 50 Hz 4600/6300 rpm
Number of clamps standard 5
