POA
For more information
If you are looking to swap out your older machine for a brand new model, fill in this short form.
Finance available on this machine working alongside our partner Close Brothers Asset Finance.
IMPORTANT
Specifications | |
|---|---|
Make | |
Model | |
Pre Milling Unit | |
Minimum Panel Length | |
Edge Thickness | |
Minimum Panel Thickess | |
End Trim | |
Motor Power | |
Corner Rounded | |
Scraping |
Specifications | |
|---|---|
Bander Type | |
Feed Speed | |
Maximum Edge Thickness | |
Minimum Edge Thickness | |
Top/bottom Trim | |
Buffing | |
Dust Outlet Size | |
Voltage/Phase | |
Weight | |
Dimensions |
FEATURES
| MACHINING FEATURES FOR FRONT WORKTABLES | ||
| Workpiece cross-section (widthxthickness) | Min. | 38 x 18 mm |
| Max. with 45° cut | 102 x 28 mm | |
| Max. with 0° cut | 150 x 28 mm | |
| Workpiece length | Min. | 100 mm |
| Max. | Not applicable | |
| Tenon dimensions | Length max. | 150 mm |
| Thickness max. | 12,7 mm (1/2″) | |
| Height | 8 ÷ 26 mm | |
| Hole or mortise dimensions | Hole diameter | 3 ÷ 16 mm (possible interpolation up to 26 mm) |
| Mortise length max. | 150 mm | |
| Mortise thickness | 3 ÷ 16 mm (possible interpolation up to 26 mm) | |
| Hole or mortise depth max. | 12,7 mm (1/2″) | |
| “Miter Door” work cycle time min. | 18s (50 frames for cabinet doors/hour) | |
| MACHINING FEATURES FOR REAR WORKTABLE | ||
| Worpiece cross-section (widthxthickness) | Min. | 38 x 18 mm |
| Max. | 150 x 50 mm | |
| Loadable workpiece length | Min. with 2 pressure cylinders | 220 mm |
| Max. | 1250 mm (STD) 1370 mm (OPT) | |
| Machinable workpiece length | Min. with 2 pressure cylinders | 220 mm |
| Max. | 1100 mm | |
| Hole or mortise dimensions | Hole diameter max. | 16 mm (doubling by interpolation) |
| Mortise length max. | 960 mm | |
| Mortise thickness | 3 ÷ 16 mm (doubling by interpolation) | |
| Hole or mortise depth max. | 50 mm | |
| Holes centre-distance max. (in X axis) | 960 mm | |
