Cehisa Edgebanders

We supply new and ex-demonstration Cehisa edgebanders, from compact single-phase machines for small joinery shops to fully automatic models for high-volume panel production. Every machine we sell is delivered, installed and commissioned by us, with operator training, servicing and Cehisa spare parts afterwards, and finance is available on all of them. If a model isn’t listed, or you need a particular specification, get in touch and we’ll quote for it. You can also browse our full range of edgebanders.

About Cehisa

Cehisa has been making edgebanders since 1968. The company is based in Caldes de Montbui, near Barcelona, where it designs and builds its machines. It sells in more than 65 countries and has sold over 40,000 machines. Edgebanding is its main business, and it makes machines for every size of workshop, from the smallest to full production lines.

The Cehisa Edgebander Range

ONE Series

Cehisa’s entry-level automatic edgebander. It runs on an industrial track, has pre-milling, and uses the T-4X unit to handle end trimming, rounding and top and bottom trimming. It takes 0.4 to 2mm edging on panels 10 to 45mm thick, and a single-phase version is available.

OPTIM Series

At 2.35m long, this is one of the most compact industrial edgebanders you can buy. It has pre-milling, vertical rounding, radius scrapers and buffers. It takes 0.4 to 2mm edging (3mm as an option) on panels 8 to 50mm thick, and is also available in single phase.

VERSA

A heavy-duty machine on a chain track feed, built to apply solid wood lippings up to 5mm as well as PVC, ABS and melamine tape up to 3mm. It has pneumatic radius and glue scrapers and a DUO-MELT glue pot that runs both EVA and PUR.

Flexy Series

A heavy-duty machine with a small footprint, controlled from a 5.6″ touch screen. The Flexy P covers pre-milling, end saws, top and bottom trimming, radius scrapers and buffing. The Flexy PC adds corner rounding and a DUOMELT glue pot.

Compact Series

The Compact PCS-Plus is the top model in the Compact series. It has pre-milling, corner rounding, a 10 m/min chain feed and touch screen control. DUOMELT glue and pneumatic controls are options.

XPERT Series

Uses Cehisa’s C-Motion technology, with up to 11 motorised axes, so you set up from the control panel rather than adjusting by hand. It takes 0.4 to 3mm edging and 5mm wood strips on panels 8 to 60mm thick, at up to 14 m/min.

Dynamic Series

The Dynamic 9 C-Motion has motorised control across 18 axes, covering pre-milling, end trimming and radius scraping. It suits workshops that switch between edge types and thicknesses often and need consistent results.

AVANT Series

Cehisa’s range for large, demanding workloads. The AVANT 4.0 uses high-frequency motors with independent converters and a large colour touch screen. The AVANT 6.0 is Cehisa’s fastest and most powerful edgebander, with an EVA/PUR glue unit, a pre-melter and the AirFlow system.

PRO 12 Industry Line

An industrial edgebander on a rigid steel frame with an industrial transport chain, controlled from a 10″ panel, for high-capacity production work.

Choosing the Right Cehisa Edgebander

• Edge thickness: the ONE and OPTIM suit tape up to 2mm. For 3mm tape or solid wood lippings up to 5mm, look at the VERSA, XPERT or above.
• Panel thickness: check the maximum panel thickness against your thickest board. It ranges from 45mm on the ONE to 60mm on the XPERT.
• Corner rounding: if you edge all four sides of doors and panels, choose a model with corner rounding, such as the Flexy PC or Compact PCS-Plus.
• Glue: DUOMELT glue pots let you switch between EVA for general work and PUR for moisture and heat resistance.
• Space and power: the ONE and OPTIM come in single-phase versions and have the smallest footprints.
• Volume and changeovers: if you change edge type several times a day, the motorised setup on the XPERT and Dynamic saves time.

If you’re unsure which model fits, tell us your panel sizes, edge materials and daily output and we’ll recommend a machine.

Cehisa Spare Parts and Servicing

We supply spare parts for the full Cehisa edgebander range, including older models. To help us find the right part, send us the machine model, serial number and age, any part numbers you have, and photos of the part. We also provide servicing, maintenance, breakdown support and repairs.
