SCM Model FS410 Nova Combined Planer Thicknesser
POA
The SCM FS410 Nova Combined Planer Thicknesser is a compact, high-quality machine that delivers exceptional stability, precision, and ergonomics for space-conscious workshops. Its 95mm cutter block with 4 knives, adjustable feed rollers, and helicoidal infeed ensure smooth, consistent planing and thicknessing. Featuring the “Xilent” spiral knife and improved dust extraction, it offers a quiet, efficient, and environmentally friendly working environment.
Product Features
- Combined planer thicknesser machine
- Simultaneous table raising system
- Connecting rod system for stability and precision
- 95 mm cutter block with 4 knives
- Adjustable feed roller pressure
- Helicoidal infeed roller for consistent feed
- Sandblasted steel outfeed roller
- Xilent spiral cutter block with rotatable inserts
- Reduced noise operation
- Compact, space-saving design
Description
Combining high productivity and solid performance in one compact machine, the FS410 Nova is a high-quality, durable, combined planer thicknesser that will make an excellent addition to space-cautious workshops.
Maximum stability and reliability are combined with excellent ergonomics thanks to the connecting rods. This system brings fluid movement, avoidance of worktable deformations and a lifetime’s worth of great precision without the noise. With simultaneously raising work tables, perfect planing is a given. The system allows for a quick, swift and hassle-free transition from operating the thicknesser to operating the planer – all with a single movement.
The planer unit utilizes a 95mm diameter cutter block with 4 knives. The pressure of the thicknesser feed roller is able to be adjusted according to the type of material being processed. The roller infeed has a helicoidal profile to ensure firm, constant workpiece feed whilst the outfeed roller (in sandblasted steel) sustains the perfect post-processing finishing.
Producing an exceptional finish, the “Xilent” spiral knife has vastly reduced noise – making for a more comfortable, less obtrusive working environment. Also adding to a more environmentally friendly, less pollutive and healthier workplace is the improved dust extraction via the small chips. The longevity of the cutter block has been greatly extended as each cutter has 4 tips which can be rotated into the cutting position when worn.
Specifications
P1 Version
Capacity 410 x 240mm
2 Feed speeds
Tersa cutter block
Length of Surfacing tables 2200mm
Powered lifting of thicknessing table
7.5hp motor – Auto star-delta
Additional over turning fence for processing thin material
| Working width | mm | 410 |
| Cutterblock diameter/standard knives | mm/no. | 95/4 |
| Total length of surface work tables | mm | 2200 |
| Three-phase motors starting from | kW/Hz | 7 (6) / 50 (60) |
- Working width mm 410
- Total length of tables mm 2200
- Infeed table length mm 1040
- Cutterblock diameter (No. of knives) mm 95 (4)
- Cutterblock speed rpm 5000
- Surface fence size mm 1200×190
- Extraction outlet diameter mm 120
- Surface fence tilt angle 90° – 45°
- Main motor power 5 Kw – 7.5 hp 50 Hz
- Extraction flow rate m3/h 1050
- Machine net weight Kg 550
