Minimax SC 3C Sliding Table Panel Saw

POA

The Minimax SC 3C is a high-precision, compact circular saw designed for woodworking workshops that require both affordability and performance. With its robust construction and advanced features, the SC 3C offers exceptional cutting quality on both thick solid wood and veneered panels, making it a reliable choice for a wide range of applications.

Key Features & Advantages:

  • Unmatched Cutting Performance
    The Minimax SC 3C delivers incredible cutting capabilities with a maximum blade diameter of 315 mm, ensuring a 100 mm cutting height even when the scoring blade is installed. This allows for clean, precise cuts on both solid wood and veneered panels, without compromising on performance.

  • Adjustable Scoring Unit
    The new scoring unit is available on request and can be easily adjusted from outside the machine. This feature ensures that users can achieve accurate, high-quality cuts with minimal effort.

  • Exclusive Precision Support
    Experience smoother, more precise cutting with a perfectly stable support system, even when handling large workpieces. The wide sliding table and large squaring frame fence, standard on the SC 3C, ensure maximum stability during operations. The system is designed for top-quality precision, providing smooth and silent action that requires no adjustment over time.

  • Self-Cleaning, Dustproof System
    The SC 3C features a self-cleaning, dustproof system that maintains long-lasting accuracy and reduces maintenance. This ensures optimal machine performance over time without requiring frequent adjustments or servicing.

  • Sturdy, High-Quality Table Construction
    The table is made of extruded anodized aluminium with a closed honeycomb structure, offering robust support for cutting operations. The sliding table runs on a precision-engineered slideway system consisting of calibrated, hardened F550 SX steel guides, ensuring smooth operation and long-lasting durability.

The Minimax SC 3C offers woodworking professionals an affordable solution without compromising on quality. Its precision, ease of use, and innovative features make it a valuable addition to any workshop looking to enhance productivity and cutting accuracy.

Out of stock

In Stock

Part Exchange

If you are looking to swap out your older machine for a brand new model, fill in this short form.

Finance Enquiry

Finance available on this machine working alongside our partner Close Brothers Asset Finance.

IMPORTANT

Technical Specifications

Specifications
Make
Model
Pre Milling Unit
Minimum Panel Length
Edge Thickness
Minimum Panel Thickess
End Trim
Motor Power
Corner Rounded
Scraping
Specifications
Bander Type
Feed Speed
Maximum Edge Thickness
Minimum Edge Thickness
Top/bottom Trim
Buffing
Dust Outlet Size
Voltage/Phase
Weight
Dimensions

FEATURES

Machines Features

Loading...

Specifications

Technical data

sc 3c
Max. sawblade diametermm / inches315 / 12
Sawblade arbor sizemm / inches30 / 1.18
Max. sawblade projection from table at 90°/45°mm / inches100/78 3.94/3.07
Cutting width on parallel fence (Rip capacity)mm / inches900 / 50
Max. squaring stroke of sliding table sawmm / ft1600 / 5.5
Single-phase motorHp4.8
